Fanvil X7 Touch Screen IP Phone

Fanvil X7 V2 Touch Screen IP Phone

The Fanvil X7 Touch Screen IP Phone is an enterprise communication terminal built for executives, managers, and high-traffic office desks. Its 7-inch capacitive touchscreen provides direct access to contacts, call records, line status, and programmable functions. Moreover, 20 Session Initiation Protocol lines, HD audio, and 116 DSS entries help users manage complex call activity through one clear interface.

Product Overview

The X7 V2 uses a 1024 × 600 colour touchscreen instead of a traditional key-based line panel. Therefore, users can review information and select call functions with fewer steps. Its display supports up to 116 DSS entries for line selection, Busy Lamp Field monitoring, speed dialling, and other assigned actions.

The phone also combines dual Gigabit Ethernet with IEEE 802.3af Power over Ethernet. As a result, one network cable can provide both data and power. Bluetooth 4.2 supports compatible wireless headsets, while an optional USB Wi-Fi dongle enables wireless network access.

Key Features

• A 7-inch capacitive touchscreen provides a spacious interface for calls, contacts, and DSS functions.
• Twenty SIP lines help executives and reception teams manage multiple extensions and calling accounts.
• Up to 116 on-screen DSS entries provide direct access to lines, contacts, and frequently used functions.
• G.722 and Opus codecs deliver HD voice through the handset and full-duplex speakerphone.
• Bluetooth 4.2 allows users to connect a compatible wireless headset for hands-free communication.
• H.264 decoding enables the phone to receive compatible video calls at resolutions up to 1080p.
• An optional CM60 USB camera adds supported two-way video communication when required.
• Six-way conferencing allows several participants to join one audio discussion.
• Dual Gigabit Ethernet ports provide fast network access and a bridged connection for a computer.
• Integrated PoE reduces cabling when the phone connects to a compatible powered network port.
• The adjustable desktop stand offers 40-degree and 50-degree viewing positions.
• Server or USB flash drive recording supports authorised business call-recording workflows.

Technical Specifications

• Brand: Fanvil
• Model: X7 V2
• Product type: Touchscreen enterprise IP phone
• Focus keyphrase: Fanvil X7 Touch Screen IP Phone
• SIP lines: 20
• Display: 7-inch 1024 × 600 capacitive colour touchscreen
• DSS capacity: Up to 116 on-screen entries
• Conferencing: Six-way audio conference
• Video codec: H.264
• Video resolution: QCIF, CIF, VGA, and 1080p
• Audio codecs: G.722, Opus, G.711a/u, G.723.1, G.726, G.729AB, and iLBC
• Bluetooth: Version 4.2
• Wi-Fi: Supported through an optional USB Wi-Fi dongle
• Ethernet: Two 10/100/1000 Mbps RJ45 ports
• USB: One Universal Serial Bus 2.0 Type-A port
• Phonebook: 2,000 local and 2,000 remote entries
• Call records: 1,000 entries
• Power: IEEE 802.3af PoE or 5V DC, 2A
• Dimensions at angle one: 268 × 185 × 189 mm
• Dimensions at angle two: 268 × 201 × 168 mm
• Operating temperature: 0°C to 45°C
• Operating humidity: 10% to 95%
• Colour: Black

Common Applications

The X7 V2 suits executive offices, reception desks, management workstations, and customer-facing business environments. In particular, its touchscreen and large DSS capacity help users who monitor many extensions. Video reception also supports compatible visual communication and door-entry workflows.

Why Choose the Fanvil X7 V2?

The Fanvil X7 Touch Screen IP Phone places call controls, line information, and contacts on one adjustable display. Therefore, users can manage busy communication tasks without relying on a large physical key panel. Its 20 SIP lines and extensive DSS capacity also support roles that handle many internal and external calls.

Furthermore, HD audio improves everyday conversations, while Bluetooth offers headset flexibility. Gigabit Ethernet, PoE, and optional Wi-Fi support different network layouts. Contact us to confirm phone-system compatibility and the accessories required for Wi-Fi or video communication.

Frequently Asked Questions

How many DSS entries does the X7 V2 support?

The X7 V2 supports up to 116 DSS entries on its touchscreen. Users can assign supported functions such as line selection, Busy Lamp Field monitoring, and speed dialling. Therefore, the phone can present many shortcuts without requiring a separate expansion panel.

Does the X7 V2 have built-in Wi-Fi?

No. The phone supports Wi-Fi through a compatible USB Wi-Fi dongle. Therefore, users who need wireless network access must add the appropriate dongle. Alternatively, the dual Gigabit Ethernet ports provide a wired network connection.

Can the X7 V2 make video calls?

The phone supports H.264 video decoding and can receive compatible video calls. In addition, Fanvil lists support for the optional CM60 USB camera. Adding the supported camera enables video communication functions that require outgoing video.

What can connect to the USB port?

The Universal Serial Bus 2.0 Type-A port supports a Wi-Fi dongle or USB flash drive. The phone also supports the optional CM60 camera. Therefore, the port can serve different functions, although only one USB device can connect directly at a time.

.
