Fanvil X3U Pro Enterprise IP Phone

Fanvil X3U Pro Enterprise IP Phone

The Fanvil X3U Pro Enterprise IP Phone is a Gigabit desk phone for professionals who manage several business extensions. It supports six Session Initiation Protocol lines, three illuminated line keys, and local six-way conferencing. Dual Gigabit Ethernet ports also serve the phone and a connected computer. Meanwhile, integrated Power over Ethernet, HD audio, and EHS headset support help create an organised call-handling workstation.

Product Overview

The X3U Pro uses a 2.8-inch 320 × 240-pixel colour display. It presents line status, caller information, contacts, and menus in a clear format. In addition, the three line keys align with the screen and provide direct access to assigned accounts or functions.

Its two 10/100/1000 Mbps Ethernet ports use a bridged arrangement. Therefore, a nearby computer can connect through the phone without reducing the link to Fast Ethernet. Integrated IEEE 802.3af PoE also allows one cable to carry both network data and electrical power.

For voice quality, the phone supports G.722 and Opus wideband codecs. It also includes acoustic echo cancellation, noise reduction, and packet-loss concealment. These tools help maintain clear audio through the handset, speakerphone, and supported headset.

Key Features

• Supports six SIP lines, enabling users to register several business extensions or compatible calling accounts.
• Provides three illuminated line keys for direct control of assigned lines and functions.
• Displays calls and menus on a 2.8-inch 320 × 240-pixel colour screen.
• Includes two Gigabit Ethernet ports for network access and computer pass-through.
• Supports IEEE 802.3af PoE, reducing the need for a separate power outlet at the desk.
• Provides a local six-way audio conference for discussions involving up to six parties.
• Uses G.722 and Opus codecs to support HD voice on compatible telephone systems.
• Supports an Electronic Hook Switch wireless headset for convenient call control.
• Stores up to 1,000 contacts in its local phonebook for quick access to business numbers.
• Supports SIP Hotspot, allowing compatible phones to share SIP account information in a supported deployment.
• Provides VLAN, LLDP, and Quality of Service tools for managed voice networks.
• Supports automatic provisioning for consistent multi-phone configuration and firmware management.

Technical Specifications

• Brand: Fanvil
• Model: X3U Pro
• Product type: Entry-level Gigabit enterprise SIP phone
• Focus keyphrase: Fanvil X3U Pro Enterprise IP Phone
• Display: 2.8-inch 320 × 240-pixel colour screen
• SIP lines: 6
• Physical line keys: 3 with LED indicators
• Conference capacity: Local six-way audio conference
• Ethernet interfaces: Two 10/100/1000 Mbps bridged ports
• Power: IEEE 802.3af PoE or optional external power supply
• Audio modes: Handset, full-duplex speakerphone and headset
• Wideband audio codecs: G.722 and Opus
• Local phonebook: Up to 1,000 entries
• Call history: Up to 600 records
• Headset support: Electronic Hook Switch
• Internet Protocol support: IPv4 and IPv6
• Network features: VLAN, LLDP, QoS and 802.1X
• Secure communication: SIP over TLS and SRTP
• Provisioning: FTP, TFTP, HTTP, HTTPS, DHCP options, SIP PnP and TR-069
• Stand angles: 45 and 50 degrees
• Installation: Desktop or wall mounting

Common Applications

The Fanvil X3U Pro Enterprise IP Phone suits reception areas, service desks, small call-handling teams, administrative offices, clinics, and retail counters. Six SIP lines help users separate departments or calling services. Furthermore, the PC pass-through port works well where one network outlet must serve both a telephone and workstation. Central provisioning also supports consistent deployment across several desks.

Why Choose This Product?

The X3U Pro combines multi-line call control with Gigabit desk connectivity. Its three line keys give users direct access to assigned accounts, while SIP Hotspot supports selected shared-account deployments. Moreover, local six-way conferencing provides broader collaboration than the three-way capacity stated in the supplied base content. PoE, EHS support, and automatic provisioning also make the phone practical for managed office installations.

Frequently Asked Questions

Does the X3U Pro support three-way or six-way conferencing?

The X3U Pro supports a local six-way audio conference. The three-way figure in the supplied base content does not match the official specification for the Pro model.

Does the phone have six physical line keys?

No. It supports six SIP lines but has three physical line keys with LED indicators. SIP accounts and physical keys describe different capacities.

What does SIP Hotspot do?

SIP Hotspot allows compatible phones on the same network to share SIP account information through a primary device. Correct operation depends on network design and telephone configuration.

Can a computer connect through the X3U Pro?

Yes. The bridged PC port lets a nearby computer share the desk’s network connection. Both Ethernet ports support speeds up to 1000 Mbps.

Does the X3U Pro have built-in Wi-Fi or Bluetooth?

No. The official product specification does not list built-in Wi-Fi or Bluetooth. Network access uses its Ethernet interfaces, while supported EHS headsets use the headset connection.

Can it work without an external power adapter?

Yes. A compatible IEEE 802.3af PoE connection can supply power and network data. An optional external power supply offers another powering method.

Can IT teams configure several phones together?

Yes. The X3U Pro supports automatic provisioning through several methods. Administrators can distribute settings and firmware rather than configuring every phone manually.

Can the stand angle be adjusted?

Yes. The desktop stand supports 45-degree and 50-degree positions. Users can select the angle that provides a comfortable view of the colour display.
